HS‑SK4T CNC servo terminal crimping machine is a vertical CNC‑driven crimping unit with 4‑ton servo crimping capacity for wires from 0.5‑16mm². Operated via touch‑screen interface, it features switchable 30/40 mm crimping stroke with optional pressure‑monitoring function. It delivers throughput up to 1200 pcs/h.

HS‑SG4T servo terminal crimping machine with 4T crimping capacity for 0.5‑16mm² cables. Featuring overhead pressure monitoring & industrial computer operation, output up to 1200pcs/h, reliable crimp solution for automotive, new‑energy, home appliance and industrial control wiring harness manufacturing.

10‑ton CNC servo crimping force accommodates medium‑to‑large cables ranging from 6‑50mm². Switchable 30/40 mm crimping strokes are compatible with various medium‑size terminals and cable lugs, providing sufficient and uniform crimping force to meet process specifications for medium‑high‑power wire harnesses.

10‑ton servo crimping force accommodates medium‑to‑large cables ranging from 6‑50mm². It features switchable 30/40 mm crimping strokes and is compatible with a wide range of medium‑size terminals and cable lugs, delivering sufficient and uniform crimping force to meet process specifications for medium‑high‑power wire harnesses.

The HS‑SG20T intelligent servo terminal crimping machine delivers powerful 20T crimping force for heavy‑duty cables from 6‑120mm². It adopts baseplate pressure monitoring with 60 mm fixed crimping stroke, reaching production capacity up to 720pcs/h. Built‑in robust frame, suitable for automotive, new‑energy, household appliance & industrial control heavy‑gauge wire harness crimping applications.

40‑ton heavy‑duty CNC servo crimping force for ultra‑large 16‑300mm² cables. 75 mm extended crimping stroke fits heavy‑duty high‑voltage terminals and large‑size cable lugs, delivering ample and uniform crimping force to meet strict high‑power high‑voltage harness crimping standards.

The HS‑SG40T intelligent servo terminal crimping machine delivers 40T ultra‑high crimping force for super‑large cables ranging from 16‑300mm². Equipped with baseplate pressure monitoring, 75mm long crimping stroke and industrial computer control, its throughput reaches 400‑500pcs/h. High‑power 4500W heavy‑duty structure, ideal for automotive, new‑energy, household appliance & industrial control extra‑large heavy‑gauge wire harness crimping applications.

The HS‑SG60T intelligent servo terminal crimping machine provides 60T super‑high crimping force for extra‑large cables of 35‑400mm². It is equipped with baseplate pressure monitoring, 75mm long crimping stroke and industrial computer control, achieving output of 200‑400pcs/h. With 7500W heavy‑duty power supply (380V), it is ideal for new‑energy energy storage, automotive, heavy‑industry and large‑scale heavy‑gauge wire harness crimping applications.

HS‑J20S fully automatic intelligent double‑end terminal crimping machine is a high‑capacity double‑end terminal crimping equipment. It operates with AC 220V 50/60Hz single‑phase power supply, has a power of 7500W, HS Code 8479819000, equipment weight 1000KG±15KG, and dimensions 680015901900mm. The production efficiency reaches 3000pcs/h.

The HS‑ZSG4T desktop intelligent servo terminal crimping machine provides 4T crimping force for fine wires ranging from 0.3‑6mm². Equipped with walk‑mounted pressure sensor, switchable 30/40 mm crimping stroke and industrial computer control, it delivers 500‑1000pcs/h output. Compact desktop footprint, ideal for automotive, new‑energy, household appliance & industrial control small‑gauge wire harness crimping applications.

60‑ton ultra‑heavy‑duty CNC servo crimping force for 35‑400mm² extra‑large cables. 75 mm extended crimping stroke fits oversized cable lugs and heavy‑duty high‑voltage terminals, providing sufficient and uniform crimping force to satisfy strict crimping standards for extra‑high‑power high‑voltage wire harnesses.

HS‑ZSK4T desktop CNC servo terminal crimping machine is a compact bench‑top servo crimping unit with 4‑ton crimping capacity for fine wires of 0.3‑6mm². Featuring switchable 30/40 mm crimping stroke and industrial computer control, with pressure sensor as optional accessory, it achieves production output of 500‑1000 pcs/h.
